ZALMAN zdroj ZM750-GVII GigaMax, 750W eff. 88%
Popis a parametry
ZALMAN zdroj ZM750-GVII GigaMax, 750W eff. 88%
| Operating Temperature | 0~40? |
|---|---|
| Protection | OCP / OVP / OPP / OTP / UVP / SCP |
| Regulatory | CB, CE, KC, EAC, RoHS |
| Model | GigaMax(GVII) 750W (ZM750-GVII) |
| Dimensions | 150(L) x 140(W) x 86(H)mm |
| Weight | 2.09kg |
| Type | Intel ATX 12V V2.31 |
| PFC | Active PEC |
| Input Voltage | 200-240VAC |
| Input Current | 6A |
| Input Frequency | 50-60Hz |
| Efficiency | Max 88% @ 230VAC, Typical load |
| MTBF | 50,000 Hours |
| Cables (Connector) | Motherboard Cable x 1 PCI Express Cable (Connector 4ea) x 2 IDE (Connector 2ea) + FDD (Connector 1ea) Cable x 1 S-ATA Cable x 1 S-ATA / IDE Cable x 1 CPU Cable x 1 |
.
ParametryPorovnání
Formát zdroje
ATX
Konektory
PCIe 8-pin
Konektory
SATA 15-pin
Konektory
FDD
Konektory
Molex
Konektory pro základní desku
ATX 24-pin
Efektivita zdroje
80 Plus Bronze
Modulární kabeláž
Ne
Výkon zdroje (W)
750
ZALMAN zdroj ZM750-GVII GigaMax, 750W eff. 88%
