ZALMAN zdroj ZM500-TXII MegaMax, 500W, 80 PLUS
| Model | ZM500-TXII |
|---|---|
| Efficiency | Max 86% @ 220VAC, Typical Load |
| Dimensions | 140(L) x 150 (W) x 86 (H) mm |
| MTBF | 100,000Hours |
| Weight | 1.63 kg |
| Operating Temperature | 10~45 ? |
| PFC | Active PFC 98% |
| Regulatory | KC, CE, CB, RoHS, EAC |
| Type | Intel ATX 12V Ver2.31 |
| Protection | OPP/OVP/UVP/SCP |
| Input Voltage | 200-240 VAC |
| Input Current | 4A |
| Input Frequency | 50-60Hz |
| Fan Size | 120mm |
| Rated Speed | 2,000RPM |
| Fan Bearing | Hydro-Dynamic Bearing |
| Cables (Connector) | Mainboard Cable CPU Cable (COnnector 2EA) PCI Express Cable ( Connector 2EA) S-ATA Cable 2EA (Connector 3EA) Peripheral FDD + Peripheral IDE (Connector 3EA) |
.
ParametryPorovnání
Formát zdroje
ATX
Konektory
FDD
Konektory pro základní desku
EPS 8-pin
Efektivita zdroje
80 Plus
Modulární kabeláž
Ne
Výkon zdroje (W)
500
