ASUS MB Sc LGA1151 P10S WS, Intel Z170, 4xDDR4, 1xDP, 1xDVI, 1xHDMI, 1xVGA

Socket (patice):Socket 1151; Formát:ATX; Integrovaná grafická karta:Ano (CPU); Chipset:Intel; Technologie paměti RAM:DDR4; PCI express 16x:Více než 1; Integrovaná LAN karta:2; Rozhraní:HDMI, VGA, DisplayPort, DVI; Další rozhraní:S/PDIF.... více
5 467.77 Kč bez DPH
Na dotaz
6 616 Kč
ks
Vyberte si zvýhodněné balení
Množstevní slevy
Kód: 417505
Kód dod.: 90SB05T0-M0EAY0
EAN: 4712900268348
Záruka: 36 Měsíc(ů)
Výrobce: Asus
Popis a parametry

ASUS MB Sc LGA1151 P10S WS, Intel Z170, 4xDDR4, 1xDP, 1xDVI, 1xHDMI, 1xVGA

  • CPU
    Build in Intel® Socket 1151 Core™ i7/Core™ i5/Core™ i3/for Xeon® E3-1200 v5 and 6th genereation CoreTM, Pentium® and Celeron® Processors
    Supports Intel® 14 nm CPU
    Supports Intel® Turbo Boost Technology
    * Refer to www.asus.com for CPU support list
  • Chipset
    Build in Intel® C236
  • Memory
    4 x DIMM, Max. 64GB, DDR4 2133 MHz ECC, Non-ECC, Un-buffered Memory
    Dual Channel Memory Architecture
    * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  • Graphic
    Integrated Graphics Processor
    Multi-VGA output support : HDMI/DVI-D/DisplayPort ports
    VGA port
    - Supports VGA with max. resolution 1920 x 1200 @ 60 Hz
    - Supports HDMI with max. resolution 4096 x 2160 @ 60 Hz / 4096 x 2160 @ 24 Hz
    - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
    - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
    Maximum shared memory of 512 MB
    Supports Intel® HD Graphics, InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
  • Multi-GPU Support
    Supports AMD Quad-GPU CrossFireX™ Technology
  • Expansion Slots
    1 x PCIe 3.0/2.0 x16 (x16/x8)
    1 x PCIe 3.0/2.0 x16 (x8 mode) *1
    1 x PCIe 3.0/2.0 x16 (x4 mode) *2
    1 x PCIe 3.0/2.0 x16 (x4 mode) *2
  • Storage
    Intel® C236 Chipset :
    8 x SATA 6Gb/s port(s),
    2 x M.2 Socket 3*3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)
    Support Raid 0, 1, 5, 10
    Intel® Rapid Storage Technology Enterprise supports
  • LAN
    Intel® I210, 2 x Gigabit LAN Controller(s)
    Support Teaming Technology
  • Audio
    Realtek® ALC1150 8-Channel High Definition Audio CODEC
    - Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
    - High quality 112 dB SNR stereo playback output (Line-out at rear) and 104 dB SNR recording input (Line-in)
    Audio Feature :
    - Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound
    - DTS Connect
    - DTS Studio Sound
    - Optical S/PDIF out port(s) at back panel
    - BD Audio Layer Content Protection
    - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
    - Audio amplifier: Provides the highest-quality sound for headphone and speakers
    - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
    - Top notch audio sensation delivers according to the audio configuration
    Separate layer for left and right track, ensuring both sound deliver equal quality
  • USB Ports
    Built-in Controller :
    4 x USB 2.0 port(s) (Type-A, 4 at mid-board)
    Built-in Controller : *4
    6 x USB 3.0 port(s) (4 at back panel, , Type-A)
    Built-in Controller :
    2 x USB 3.1 port(s) (2 at back panel, , Type-A + Type-C)
  • Special Features
    ASUS EPU :
    - EPU
    ASUS Digital Power Design :
    (3 -phase for CPU, 2 -phase for iGPU)
    - Industry leading Digital 1 Phase DRAM Power Design
    ASUS Quiet Thermal Solution :
    - Stylish Fanless Design Heat-sink solution
    ASUS EZ DIY :
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash
  • Operating System Support
    Windows® 10
    Windows® 8.1
    Windows® 7 SP1
    Windows® Server 2008 R2
    Windows® Server 2012 R2
  • Back I/O Ports
    1 x DVI-D
    1 x DisplayPort
    1 x HDMI
    2 x LAN (RJ45) port(s)
    1 x USB 3.1 Type-A
    1 x USB 3.1 Type-C
    4 x USB 3.0
    1 x Optical S/PDIF out
    1 x 8-channel Audio I/O
    1 x VGA
  • Internal I/O Ports
    1 x AAFP connector
    1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s)
    2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
    2 x M.2 Socket 3
    1 x COM port(s) connector(s)
    8 x SATA 6Gb/s connector(s)
    1 x CPU OPT Fan connector(s) (1 x 4 -pin)
    1 x CPU fan with PWM control
    4 x Chassis Fan connector(s) (4 x 4 -pin)
    1 x S/PDIF out header(s)
    1 x 8-pin EATX 12 V Power connector
    1 x 6-pin EATX 12 V_1 Power connector(s)
    1 x 24-pin EATX Power connector(s)
    1 x System panel(s) (Q-Connector)
    1 x DRCT header(s)
    1 x MemOK! button(s)
    1 x EPU switch(es)
    1 x Power-on button(s)
    1 x Clear CMOS button(s)
    1 x USB BIOS Flashback button(s)
    1 x 14-1 pin TPM connector
  • Accessories
    User's manual
    I/O Shield
    1 x COM port cable(s)
    8 x SATA 6Gb/s cable(s)
    2 x M.2 Screw Package
    1 x Q-connector(s) (2 in 1)
    1 x SCD
  • BIOS
    16 MB Flash ROM, EFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 5.0a, ASUS EZ Flash Utility, ASUS CrashFree BIOS 3
  • Manageability
    WfM 2.0, DMI 3.0, WOL by PME, WOR by PME, PXE
  • Form Factor
    ATX Form Factor
    12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
  • Note
    *1 Switched from PCIEX16_1
    *2 From PCH
    *3 6 x SATA 6Gb/s with 2* M.2 (SATA 6Gb/s & PCIe Gen3 x1 link, NGFF 22110/2280/2260/2242)
    *4 6 x USB 3.0 ports (2 ports Type A at front panel, 4 ports Type A at back panel)
.
Technologie paměti RAM
DDR4
Rozhraní
DVI
Socket (patice)
Socket 1151
Formát
ATX
Integrovaná grafická karta
Ano (CPU)
Chipset
Intel
PCI express 16x
Více než 1
Integrovaná LAN karta
2
Další rozhraní
S/PDIF
